Features:
1. The machine is widely applicable for cutting of nonmetal materials in various industries by cutting die;
2. Adopt double oil cylinder, precise double-crank connecting rod mechanism, which can guarantee that the cutting depth at every cutting position is same;
3. With special setting mechanism, and equipped with die cutter and cutting depth setting, the travel adjustment is simple and accurate;
4. The pressing board of cutting carries out slow cutting when it contacts the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials;
5. The Full Head series has a strong exterior reinforced construction consisting of heavy duty weldments. This press is built for the long term which our customers expect;
6. Very efficient for making clean cuts of multiple layers of material;
7. Simple to learn - Die height and material height can be reset in less than ten seconds with easy to use controls for setting die and material height which provides a fast set up time;
8. Low electrical power consumption which helps make the machine very quiet;
9. Low maintenance due to an automatic central lubricating system which continuously lubricates all of the main bushings and bearings.
Specifications:
|
Maximum cutting force |
350KN |
400KN |
500KN |
600KN |
800KN |
1000KN |
1300KN |
1500KN |
2000KN |
|
Tension distance (mm) |
50-200 |
50-200 |
50-200 |
50-200 |
50-200 |
50-200 |
50-200 |
50-200 |
50-200 |
|
50-245 |
50-245 |
50-245 |
|||||||
|
Cutting area(mm) |
1600*610 |
1600*610 |
1600*800 |
1600*900 |
1600*900 |
1600*900 |
1600*1000 |
1600*1000 |
1600*1000 |
|
1250*610 |
1250*610 |
1250*800 |
1400*900 |
1400*900 |
1400*900 |
1400*1000 |
1400*1000 |
1400*1000 |
|
|
Motor power |
2.2kw |
3kw |
4kw |
5.5kw |
7.5kw |
7.5kw |
11kw |
11KW |
11kw |
|
G.W(kg) |
2100 |
2300 |
3800 |
4800 |
6300 |
7800 |
10000 |
11500 |
13500 |
|
1900 |
2000 |
3600 |
4600 |
6100 |
7600 |
9500 |
11200 |
13000 |
