HC-DA02 Automatic Full Beam Press

  • Model:HC-DA02
  • Table size:1800*900mm
  • Size:2400*3000*1600mm
  • Weight:4500KG
  • Description: HC-DA02 Automatic Full Beam Press
  • INQUIRY   EMAIL


Features:


1.This machine is suitable for cutting various non-metallic rolled material continuously.  It is of high efficiency, large capacity;

2.The whole machine adopts PLC controlling and is operated by human-machine interface(touch screen).  It is convenient to set longitudinal feeding parameters and cutting depth parameter on touch screen;

3.The whole machine adopts four-column guide, precision double crank balance, hydraulic drive. The movement part adopts central automatic lubrication system, which can ensure the service life and cutting accuracy;

4.Hydraulic system is specially designed and achieve rapid drop through gravity of pressure plate. It will cut slowly and automatically if press the  material. No worries of oil temperature rising;

5.There is manual, semi-auto and automatic working mode and suitable for different cutting requirements;

6.Use flywheel energy storage to achieve high cutting and save electricity. No worries of oil temperature rising;

7.Machines  is equipped with automatic cutting die setting device. It can automatically set itinerary according to the height of die cutter and is controlled by servo motor.  Cutting precision can be precise adjustment on man-machine interface;

8.Machines is equipped with four-column trimming die institutions, which can extend the service life of conveyor belt;

9.Machine is equipped with a pneumatic clamping device and easy for replacing the cutting die;

10.Main sealing element is original German brands. The key hydraulic parts and electrical appliances are imported and durable .

11.In order to ensure the service life of the machine, the surface of the cylinder and piston rod on mainframe is of high-frequency hard chromium plating processing.
