GSB-2C Swing Arm Cutting Press

  • Cutting pressure:20T
  • Table size:1000*500mm
  • Beam width:350mm
  • Weight:900KG
  • Description: GSB-2C Swing Arm Cutting Press
  • INQUIRY   EMAIL

USE AND CHARACTERISTICS:

1. The machine is applicable to cutting of various nonmetal materials by cutting tools.

2. The use of time control allows for simple and convenient setting of cutter depth.

3. Operation with both hands, safe and reliable.

4. The inertial energy of flying wheel is used so that the energy consumption is low and the operation stable.

5. The whole machine uses self-lubricating system to reduce wear and extend the service life of the machine.


TECHNICAL SPECIFICATION:

Model

GSB-2C/12

GSB-2C/16

GSB-2C/20

Maximum cutting force

120KN

160KN

200KN

Adjustable stroke(mm)

5-75

5-75

5-75

Tension distance(mm)

60-120

60-140

60-150

Swing Arm Width(mm)

450*320

450*320

500*350

Motor power

0.75kw

1.1kw

1.5kw

Working table (mm)

800*400

900*400

1000*500

G.W

450kg

600kg

900kg
