F60 Swing Arm Clicker Press

  • Cutting pressure:27T
  • Table size:1000*500mm
  • Beam width:500mm
  • Size:1000*1000*1500mm
  • Description: F60 Swing Arm Clicker Press,swing arm cutting machine,cutting press,clicker press
  • INQUIRY   EMAIL


Automatic stroke end with pressure switch to use cutting-knives of different height, without any adjustment, + ELECTRONIC CUT.


ELECTRONIC CUT:

This simple and innative system permits die cutting of various depths without the need for changing adjustment settings. This system also permits working with very small dies without cutting into the cutting block.


Main technical data:

Model

F45

F50

F60

Max.Cutting Force

20T

27T

27T

Maximum Stroke

80mm

100 mm

100 mm

Cutting Table

900 x 430(mm)

900 x 450(mm)

1000 x 500(mm)

Arm Width

370 mm

380 mm

500 mm

Motor Power

1HP

1.5HP

1.5HP

Electric Supply Voltage

3x440/415/400/380/220V, 50/60 Hz

Single phase 240V/220V, 50/60 Hz

Net Weight With Oil

570Kg

780Kg

840Kg

Gross weight

640Kg

900Kg

980Kg

Packing Size

1050 x1085x 1500(mm)

1050 x 1150 x 1570(mm)

1150 x 1150 x 1570(mm)
